Rear view
The following items are important for the optimal operation of the machine.
| Nr. | Description | More information |
|---|---|---|
| 1 | Fuel tank | Capacity 170 litres |
| 2 | Left-hand side flax-laying section | Moveable to the left (field) and to the right (road) |
| 3 | Right-hand side flax-laying section | Fixed position |
| 4 | AdBlue tank | Maximum 20 litres, minimum of 10 litres required for optimal operation |
| 5 | Engine compartment | In addition to diesel engine, also other hydraulic pumps and filters |
| 6 | Radiator | For cooling and working fluids |
| 7 | Battery key | For isolating electrical power supply |
| 8 | Hydraulic tank | For storage of hydraulic oil |
| 9 | Electrical cabinet | For control of some machine functions |
